Battery powered golf cars and electric vehicles have unique power requirements that U.S. Battery understands. Maintaining peak capacity for longer periods between charges, means greater vehicle reliability and lower annual operating costs. This is why U.S. Battery Electric Vehicle Deep Cycle Batteries are engineered with the company’s exclusive XC2™ formulation and Diamond Plate Technology®. This creates the industry’s most efficient battery plates, delivering greater watt-hours per liter and watt-hours per kilogram than any other flooded lead-acid battery in the market. All of our deep cycle Flooded Lead Acid batteries are Handcrafted in the USA.
FEATURES:
XC2™ Formulation: The industry’s most efficient uniform layers of tetrabasic sulfate crystals (battery cell-plate paste) enable U.S. Battery products to achieve the highest initial capacity and highest rated capacity on the market.
Diamond Plate Technology®: The most efficient cell paste requires an effective structure to hold it in position. U.S. Battery’s Diamond Plate Technology® is a unique cell plate design that when combined with XC2™ Formulation, creates the most efficient cell-plate design in the industry. This translates to greater overall capacity, longer battery life and the ability to reach peak capacity in fewer cycles.
Rugged Construction: Made with a tough polypropylene exterior case and hand cast heavy-duty connector lugs, U.S. Battery Electric Vehicle Deep Cycle Batteries can take the rigors of use in a variety of vehicles.
SpeedCap® Venting Positive Locking System: U.S. Battery makes it easy to conduct maintenance with a removable vent system that’s easy to operate and locks in place.
20 Hour Rate: 208
Minutes of Discharge @ 75 Amps: 107
Minutes of Discharge @ 25 Amps: 392
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 220
Minutes of Discharge @ 75 Amps: 115
Minutes of Discharge @ 25 Amps: 445
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 232
Minutes of Discharge @ 75 Amps: 122
Minutes of Discharge @ 25 Amps: 474
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 242
Minutes of Discharge @ 75 Amps: 140
Minutes of Discharge @ 25 Amps: 517
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 251
Minutes of Discharge @ 75 Amps: 154
Minutes of Discharge @ 25 Amps: 562
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 7/8” (302mm)
20 Hour Rate: 255
Minutes of Discharge @ 75 Amps: 159
Minutes of Discharge @ 25 Amps: 570
Length: 11 5/8” (295mm)
Width: 7 1/8” (181mm)
Height: 11 5/8” (295mm)
20 Hour Rate: 280
Minutes of Discharge @ 75 Amps: 178
Minutes of Discharge @ 25 Amps: 635
Length: 11 5/8” (295mm)
Width: 7 1/8” (181mm)
Height: 11 5/8” (295mm)
20 Hour Rate: 155
Minutes of Discharge @ 56 Amps: 110
Minutes of Discharge @ 25 Amps: 312
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 170
Minutes of Discharge @ 56 Amps: 118
Minutes of Discharge @ 25 Amps: 325
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 183
Minutes of Discharge @ 56 Amps: 136
Minutes of Discharge @ 25 Amps: 365
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 1/4” (286mm)
20 Hour Rate: 205
Minutes of Discharge @ 56 Amps: 164
Minutes of Discharge @ 25 Amps: 435
Length: 10 1/4” (260mm)
Width: 7 1/8” (181mm)
Height: 11 7/8” (302mm)
20 Hour Rate: 85
Minutes of Discharge @ 75 Amps: 38
Minutes of Discharge @ 25 Amps: 145
CCA @ 0 Degrees (F) -18 Degrees (C): 400
Length: 10 7/8” (276mm)
Width: 6 3/4” (171mm)
Height: 9 3/8” (238mm)
20 Hour Rate: 105
Minutes of Discharge @ 75 Amps: 54
Minutes of Discharge @ 25 Amps: 205
CCA @ 0 Degrees (F) -18 Degrees (C): 575
Length: 12 3/4” (324mm)
Width: 6 3/4” (171mm)
Height: 9 3/4” (248mm)
20 Hour Rate: 130
Minutes of Discharge @ 75 Amps: 59
Minutes of Discharge @ 25 Amps: 225
CCA @ 0 Degrees (F) -18 Degrees (C): 620
Length: 13” (330mm)
Width: 6 3/4” (171mm)
Height: 9 5/8” (243mm)
20 Hour Rate: 145
Minutes of Discharge @ 56 Amps: 95
Minutes of Discharge @ 25 Amps: 270
Length: Without Handles– 13 1/8” (333mm)
Length: With Handles– 14″ (355mm)
Width: 7 1/16” (179mm)
Height: 11 3/8” (289mm)
20 Hour Rate: 155
Minutes of Discharge @ 56 Amps: 110
Minutes of Discharge @ 25 Amps: 292
Length: Without Handles– 13 1/8” (333mm)
Length: With Handles– 14″ (355mm)
Width: 7 1/16” (179mm)
Height: 11 3/8” (289mm)
20 Hour Rate: 210
Minutes of Discharge @ 75 Amps: 120
Minutes of Discharge @ 25 Amps: 460
Length: 10.24” (260mm)
Width: 7.09” (180mm)
Height: 10.79” (274mm)
20 Hour Rate: 215
Minutes of Discharge @ 75 Amps: 112
Minutes of Discharge @ 25 Amps: 500
Length: 12.05” (306mm)
Width: 6.61” (168mm)
Height: 8.98” (228mm)
20 Hour Rate: 180
Minutes of Discharge @ 56 Amps: 120
Minutes of Discharge @ 25 Amps: 381
Length: 10.2” (260mm)
Width: 7.17” (182mm)
Height: 11.3” (286mm)
20 Hour Rate: 35
Minutes of Discharge @ 75 Amps: N/A
Minutes of Discharge @ 25 Amps: 41
Length: 7.68” (195mm)
Width: 5.12” (130mm)
Height: 7.13” (181mm)
20 Hour Rate: 108
Minutes of Discharge @ 75 Amps: 55
Minutes of Discharge @ 25 Amps: 220
Length: 12.05” (306mm)
Width: 6.61” (168mm)
Height: 9.17” (233mm)
20 Hour Rate: 117
Minutes of Discharge @ 75 Amps: 45
Minutes of Discharge @ 25 Amps: 207
Length: 12.9” (328mm)
Width: 6.77” (172mm)
Height: 8.66” (220mm)
20 Hour Rate: 150
Minutes of Discharge @ 75 Amps: 90
Minutes of Discharge @ 25 Amps: 323
Length: 12.87” (327mm)
Width: 7.09” (180mm)
Height: 10.79” (274mm)
